page 7 of 42
The following instructions have the purpose of
giving instructions on installation of a good ue,
however they do not replace in any way the
standards in force of which a qualied builder
must be aware. The stove manufacturer cannot
be held in any way liable in civil or criminal terms
for poor operation of the stove due to a wrongly
sized ue and/or non-compliance with legislation
in force, which must be complied with. The ue
must be built to standard and category ≥ T200 or
higher, with a vertical progression without choking,
resistant to condensate and resistant to re caused
by soot. It must be externally insulated to avoid
smoke cooling and it must have a condensate
drain. If the ue is a cement shaft, it must be
ducted. The ue must be inspected for cleaning
and must also be distanced from ammable and/
or combustible materials.
The opening area for smoke evacuation must be at
least double the section of the ue and must prevent
snow and animals entering. The measurement of
the opening in the atmosphere must be outside
the backow zone caused by the shape of the roof
and/or any obstacles found nearby. Pay attention
to the presence of skylights and dormer windows.
The minimum distances to comply with from any
chimneys or reux zones are outlined below.
Check the negative pressure between the ue
and the environment installed comply with the
instructions in the technical characteristics. The
minimum height of the ue is 3.5 metres and must
have an internal section that allows compliance
with these requirements and however not over
100mm. Check the correct congurations using
UNI EN 13384-1.
The ue must always be clean. Any soot residue
reduces the section of the ue which would
compromise draught and the soot could catch
re. Have a professional chimney sweep clean
the ue and the chimney at least once a year and
before switching on the generator after periods of
inactivity. Lack of cleaning will negatively impact
correct operation of the equipment.
Installation of the ue is not
permitted shared with other
equipment.
Flue
Chimney
30° ROOF
45° ROOF
60° ROOF15° ROOF
FLAT ROOF
A = MIN. 1,30 metri
B = DISTANZA > 1,50 metri
C = DISTANZA < 1,50 metri
D = 0,50 metri OLTRE IL COLMO
E = 0,80 metri
F = BACKFLOW ZONE
A = MIN. 0,50 m
B = DISTANCE > 2,00 m
C = DISTANCE < 2,00 m
D = 0,50 metri
E = TECHNICAL VOLUME
A = MIN. 2,00 m
B = DISTANZA > 1,30 metri
C = DISTANZA < 1,30 metri
D = 0,50 m OVER THE RIDGE
E = 1,50 metri
F = BACKFLOW ZONE
A = MIN. 1,00 m
B = DISTANCE > 1,85 m
C = DISTANCE < 1,85 m
D = 0,50 m OVER THE RIDGE
E = 0,50 metri
F = BACKFLOW ZONE
A = MIN. 2,60 m
B = DISTANZA > 1,20 m
C = DISTANZA < 1,20 m
D = 0,50 m OVER THE RIDGE
E = 2,10 m
F = BACKFLOW ZONE
