1. Lighting button
2. Fuse F4AL250V
3. Thermostat reset button
4. Environmental probe
4
3
1
2
Replace the batteries of the remote control
If you need to replace the batteries of the remote control,
remove the back cover as shown in the picture. Replace the
old batteries with the new ones respecting the polarity + and
-. The batteries needed are AAA, 1,5 V.
