PARAMETER UNIT OF M. MIGNON6 / PETITE6
Heat input (min-max) kW 3,3 - 7
Nominal heat output (min-max) kW 3,1 - 6,2
Reduced heat output kW 2,5
CO concentration at nominal reference (13% O
2
)
mg/m
3
185,6
CO concentration at reduced reference (13% O
2
)
mg/m
3
633,2
Nominal ef ciency % 88,5
Reduced ef ciency % 89,8
Pellet consumption (min-max) Kg/h 0,7 - 1,4
Flue gas ow rate (min-max) g/s 3,2 - 4,5
Draft advised (min-max) Pa 5 - 8
Flue gas temperature (min-max) °C 124 - 169
Tank capacity Kg 11
Recommended fuel (ø x H) mm pellet 6 x 30
Diameter smoke outlet tube mm 80
Diameter air intake mm 50
Nominal voltage V 230
Nominal frequency Hz 50
Power consumption max W 300
Power consumption at nominal power W 53
Power consumption at reduced power W 62
Stove weight Kg 45
N° Test Report 2004858
It is recommended that the control of emissions after installation.
The pellets are cylinders of compressed wood, produced from sawdust and wood processing (chips and
sawdust), generally produced by sawmills and carpenters. The binding capacity of the lignin
contained in wood, allows to obtain a compact product without adding additives and
foreign chemicals to the wood, is therefore obtained a natural fuel with high yield.
The use of expired pellets or any other unsuitable material can damage parts of the
thermostove and impair proper operation: this can lead to the termination
of the guarantee, and its producer responsibility.
For our products use pellets diameter 6 mm, length 30 mm and
a maximum of 8% and A1 certi ed according to the UNI EN ISO
17225-2 standard. Keep the pellets away from heat sources and
not in humid environments or with explosive atmosphere.
