SECTION 7 – SYSTEMS AND OPTIONS
Thru - Hulls
25’ / 27’ Thru-Hull layout
1. Baitwell drain
2. Bilge pump discharge
3. Bilge pump 2 discharge (25’ / 27’ only)
4. Grey water tank vent (25’ / 27’ only)
5. Grey water pump out (25’ / 27’ only)
6. Livewell discharge (Optional)
7. Sink drain (25’ / 27’ only)
8. Fresh water deckfill (25’ / 27’ only)
9. Fish box macerator discharge (25’ / 27’ only)
10. Grey water overboard discharge (25’ / 27’ only)
NOTE: On 24’ / 25’ / 27’ models the fuel fill cap is located on the port side of the transom.
IMPORTANT: Check with the Coastguard and local authorities prior to discharging any
grey water overboard.
