KI 9000 UM-14
9
GENERAL SAFETY SUMMARY
Kingfisher Laser Eye Safety Information
This information on laser eye safety compliance covers all standard
product variants.
Wavelength
Visual laser 635 / 650 ± 5 nm
Surface emitting LED
3
850 /1300 ±50 nm
VCSEL laser 850 ±20 nm
Infra-red laser 1310 / 1490 / 1550 / 1625 ±20 nm
Max CW output power¹
635 nm visual laser 0.63 mW
650 nm visual laser 5.01 mW
850 / 1300 nm surface emitting LED
3
0.01 mW
850 nm VCSEL laser 0.63 mW
1310 / 1490 / 1550 / 1625 nm infrared laser 1.00 mW
International Standard IEC 60825-2:2021 & IEC 60825-1:2014
Wavelength Instrument hazard level
635 nm Class 1
650 nm Class 2M
850 / 1300 / 1310 / 1490 / 1550 / 1625 nm Class 1
USA Standards ANSI Z136.2 / 21 CFR 1040.10 (1995)
Labelling for this product defers to IEC 60825 as per CDRH Laser
Notices No. 50 (2007) & 56 (2019). Annual FDA reports are lodged
by Kingfisher.
Maximum permissible CW output power²
IEC 60825-2:2021 – Class 1
650 nm, MM or SM fiber 1.95 mW
850 nm, MM or SM fiber 3.88 mW
1310 nm, MM fiber 77.8 mW
1310 nm, SM fiber 25.8 mW
1550 nm, SM fiber 10.2 mW
Note 1: Specified CW output power is the optical power that the Source can produce at
its output connector. Refer to specification sheet for actual operating power.
Note 2: Maximum permissible CW output power is the highest optical power that is
permitted within the appropriate laser class. Refer to specification sheet for actual
operating power.
Note 3: LED devices are no longer identified in the latest revision of IEC 60825-1.
WARNING!
Optical power levels in fiber optic systems can cause permanent eye
injury and damage to eyesight.
