KI 9000 UM-10 43
QUICK REFERENCE GUIDE – KI 9600 Series Optical Power Meter
To remove interchangeable connector adaptor, press
the button on the front of the instrument and pull off
adaptor.
To defeat auto power-off, press and hold [POWER] for
3 seconds during turn on. ‘Perm’ is displayed on the top
right of the LCD.
Low battery is indicated with a battery symbol.
During instrument turn on:
- to view all display segments, press and hold []
- to turn buzzer off, press and hold []
- to display firmware version, press and hold
[HOLD]
- to start Slow mode, press and hold [dB/dBm/mW
Set Ref]
To scroll wavelength, press [] or [].
To toggle logarithmic/relative/linear display modes,
press [dB/dBm/mW].
To stop / start display update, press [HOLD].
To set reference, press and hold [Set Ref] for more
than 3 sec. When in reference mode, the reference
value is shown on the left hand side of the display.
To display max min recorded power, press and hold
[Max Min]. To re-set this function, press [POWER].
When multi-fibre ID tone is detected by a power
meter, a buzzer will sound and the corresponding
fiber ID number will be displayed. This function is
disabled in SlowMode.
When a standard tone is detected (eg 270 Hz, 1 KHz,
2 KHz), a buzzer will sound and the corresponding
modulation frequency will be displayed.
If the meter detects a test tone higher than 200 Hz,
the display will show the actual measured modulation
frequency in kHz. This function is disabled in
SlowMode.
SlowMode:
In SlowMode, the display will show average optical
power of the modulated signal. All tone detection is
disabled
