PERFORMANCE VERIFICATION TESTS
Model: ________________________ Report No: ______________ Date: ________________
Accuracy Test
Test Wavelength =
Setting
Number
Power meter
Reference value
Attenuator
Setting
Minimum Specification
(-0.3 dB of Reference)
DUT
Measurement results
Maximum Specification
(+0.3 dB of Reference.)
1.
(~- 10.00 dBm)
dB
(~- 10.30 dBm)
dBm
(~- 9.70 dBm)
2.
(~- 20.00 dBm)
dB
(~- 20.30 dBm)
dBm
(~- 19.70 dBm)
3.
(~- 30.00 dBm)
dB
(~- 30.30 dBm)
dBm
(~- 29.70 dBm)
4.
(~- 40.00 dBm)
dB
(~- 40.30 dBm)
dBm
(~- 39.70 dBm)
5.
(~- 50.00 dBm)
dB
(~- 50.30 dBm)
dBm
(~- 49.70 dBm)
Measurement Uncertainty
dB
Note 1: Minimum/Maximum Specification is for the KI 9600-InGaAs. For the KI 9600-Ge, increase/reduce by ±0.2 dB. For the KI 9600-H3B, increase/reduce by ± 0.1 dB.
Table 4. Accuracy Test Record for KI 9600 Series Optical Power Meter
