The first step
Insert component 1 into component 2 for fixing,
with screws M5*8 at the bottom and M5*30 at the back
M5*8
M5*30
The second step
Lock the Z-axis fixing block
The third step
Insert T - screw into T - nut, link and lock with coupling
T-lead screw
Fixed block
Step four
Fix the material rack on the Z-axis 2040 aluminum profile
with M5*8 screws, and place the material tube
Secure to the material rack
