10
-12 CK22
1. Remove the filling plug from the left
top and the drain plugs from the both
side bottom and drain oil.
2. Install the drain plugs to the both side
bottom and fill the reservoir with oil.
3.Check oil level with an oil gauge.
(Refer to section 10-10 or 10-27).
CHANGING FRONT AXLE
CASE OIL
(1) Check Plug (2) Filling Plug
(3) Drain Plug
051OA19C
Oil Capacity 0.82 U.S.gals. (3.1 )
1. To drain the used oil, remove the
drain plugs at the bottom of the trans-
mission case and differentials. Drain
the oil completely into a drain pan.
2. After draining reinstall the drain plug.
3. Fill with the new fluid to the upper
line of the gauge.
(See "LUBRICANTS" in Maintenance
Section)
4. After running the engine for a few
minutes, stop it and check the oil
level again; add oil to prescribed
level.
Oil
capacity
4.89 U.S.gals.
(18.5
)
5.71 U.S.gals.
(21.6
)
CK20
CK20H
