Kioti CS2520H - OPERATING THE CONTROLS

4
-
15
DESCRIPTION OF OPERATING SYSTEM
4
OPERATING THE CONTROLS
1
2
3
4
5
6
9
10
11
7
12
13
8
1
2
3
4
5
6
9
10
11
7
12
1414
13
8
tb3O425A
(1) Hand Throttle Lever
(2) Brake Pedal
(3) Parking Brake Lock Lever
(4) HST Forward Pedal
(5) HST Reverse Pedal
(6) Range Gear Shift Lever
(7) Double Acting Lever (A,B)
(8) Lift Position Control Lever
(9) PTO
Select Lever
(10) Mower Deck Lever
(11) Cruse Control Switch
(12) Joystick Lever
(13) Joystick Lock Lever
(14) PTO ON/OFF Switch
