4-8 DK451/501/551
A12O408A
PTO CHANGE SWITCH
(MT/AT)
(1) PTO Change Switch (N) Neutral
(A) Auto (B) Manual
The PTO change switch must be placed
to the “neutral” position before starting
the engine. Otherwise, the engine will not
start. When turning PTO change switch
to Automatic, the PTO operates only when
the implement is in the lowered position.
For example, if you lift the implement while
working, the PTO will stop. If the PTO
change switch is in the Manual position,
the PTO will operate continuously.
IMPORTANT
Always turn the starter switch key
to the “OFF” position. Damage
may occur to the electrical sys-
tem if the engine is running with
the starter switch off.
When a hazard lamp switch is pulled to
on position, the hazard lamps blink.
HAZARD LAMP SWITCH
(1) Hazard Lamp Switch
(A) Hazard Lights OFF (B) Hazard Lights ON
CAUTION
When it is used for a long time, a
lot of electricity will be used.
Therefore, it must be used only
in case of emergency.
A12O409A
