4-18 DK451/501/551
MAIN / HI-LOW SHIFT LEVER
(1) Main Shift Lever (2) Hi-Low Shift Lever
A12O426B
The main shift lever pattern is in the form
of an “H”. The range lever is used to se-
lect three stage, “High”, “Middle” and
“Low”. By combination and use of the
main shift lever and the range lever, it is
possible to obtain four speeds forward
and reverse in “High” range, four speeds
forward and reverse in “Middle” range
and four speeds forward and reverse in
“Low” range, or a total of twelve speeds
forward; and twelve speeds reverse,
High, Middle and Low.
CAUTION
To change speed, press the clut-
ch pedal completely down before
attempting to proceed with speed
change.
DK501/551
DK451
