LOADER SPECIFICATIONS 3-3
2,338 lb1,061 kgLift Capacity to Full Height at Pivot PinsS
4,700 lb2,132 ㎏fBreakout Force at Pivot PinsT
Ø2.4×31.2 "Ø35x60x700x480 STLift Cylinder
Ø2.4×43.7 "Ø35x60x998x332 STBucket Cylinder
67.0 "1,700 mmBucket Width
260 lbs118.1 KgBucket Weight
1,491 lb676 kgApprox. Weight (without Bucket)
15.9 cu.ft0.45 ㎥Bucket Capacity
16.5 "419 mmReach at Maximum Height(45°)D
60.8 °Maximum Dump AngleE
72.5 1,842 mmReach with Attachment on GroundF
48.4 °Attachment Rollback AngleG
4.7 "119 mmDigging Depth Below GradeH
63.7 "1,617 mmOverall Height in Carry PositionJ
23.3 "592 mmDepth of Attachment (to back of inner shell)L
22.9 "581 mmHeight of AttachmentM
31.5 "800 mmDepth of Attachment (to pivot pin)N
79.8 "2,026 mmClearance with Attachment DumpedC
98.7 "2,506 mmClearance with Attachment LevelB
110.0 "2,794 mmMaximum Lift HeightA
