13-2 KL155
GENERAL INFORMATION
Illustrations
The individual parts in their normal relationship to each other. Reference numbers are used in the illustrations. These numbers
correspond to those in the "Number" column and are followed by the quantity required and description.
Directional Reference
"Right hand" and "left hand" sides are determined by standing at the rear of the unit and facing in the direction of forward travel.
Part Order
Orders must give the complete description, correct part number, the total amount required, the product model, all the necessary
serial numbers, the method of shipment and the shipping address.
Instructions
1. GROUP NAME
: Detail classification name for parts.
2. SECTION NAME
: Classification name for parts.
3. COMPONENTS
: The components of an assembly are identified by a bracket.
4. NO.
: Reference numbers are assigned to parts in the figure.
