Kioti KL155 - Page 74

PART ILLUSTRATIONS 13-15
10191-M1606-90
10191-M1205-45
10121-M0803-FM
1021M-M2404
14124-25110-N
14124-25130-N
14152-25113
14116-16102
FTF40-20300
FTF40-20200-02
FTF40-20101-02
FTF40-53100
FTF40-52400
FTF40-52300
FTF40-52200
FTF40-52100
FTF40-55100-01
FTF40-54100-01
FTF40-51500-01
FTF40-51600-01
FT105-32100-02
FT105-31100-02
FTF40-11100-03
PART No.
18Nut-SelfLock, M24×1.5P20
2Bolt Ass'y, M8×1.25P 25L21
2Hex-Bolt-HT, M12×1.75P 45L22
1Link-L/H5
2Link-Level6
2Safety bar7
1Link W.A.-Bucket8
1Link W.A.-Bucket9
1Link W.A.-Bucket10
1Link W.A.-Bucket11
2Link W.A.12
2Stand13
2Stand bar W.A.14
2Bolt W.A.15
2Pin-Hand, ∅16×110L H67.516
2Pin W.A., ∅25×106.3L17
16Pin, M24×1.5P 130L18
2Pin, M24×1.5P 110L19
I.C
2Hex-Bolt-HT, M16×2.0P 90L23
1Link-R/H4
1Post W.A.- LH3
1Post W.A.- RH2
1Boom Ass'y1
REMARKQ'tyDESCRIPTIONREF. NO
13
