Kioti KL155 - Page 80

PART ILLUSTRATIONS 13-21
50120-M270K
50135-1650K
80620-04003
8044W-03300
8044Y-03300
8044B-03300
8044R-03300
80410-T3360
10211-M1004
10191-M1004-30
1012S-M0803-35
FTF40-62102
FTF40-62101
FTE37-10001-03
80620-03011
80620-03017
80620-01027
PART No.
4Clamp28
1Clamp29
11Bolt-Sem's, M8×1.25P 35L30
2Hex-Bolt-HT, M10×1.5P 30L31
2Hex-Nut, M10×1.5P32
4Quick Coupler, PT3/8" Male33
1Dust-Cap, 3/8" Red Female34
1Dust-Cap, 3/8" Blue Female35
1Dust-Cap, 3/8" Yellow Female36
1Dust-Cap, 3/8" White Female37
4Hyd Hose, 1(PT3/8)×2(3/4-16UNF) 1900L(3/8)38
1Webbing, 1650L39
2Cable Tie, 270mm Black40
I.C
1Cover, Pipe27
1Hyd Hose, 4(3/4-16UNF)×2(3/4-16UNF) 450L(3/8)26
1Hyd Hose, 4(3/4-16UNF)×2(3/4-16UNF) 900L(3/8)25
1Hyd Hose, 4(3/4-16UNF)×4(3/4-16UNF) 450L(3/8)24
REMARKQ'tyDESCRIPTIONREF. NO
13
