Kioti KL155 - Page 82

PART ILLUSTRATIONS 13-23
80620-03017
80620-03011
80620-01044
80620-01027
FTF40-HP700
FTF40-HP800
FTF40-HP600
FTF40-HP500
FTF40-HP400
FTF40-HP320
FTF40-HP310
FTF40-HP100
FTF40-HP210
81301-BP014
802H1-F94F9-40
802L2-P46F9-42
802N2-P46F9-42
801T1-50000
14711-D0011
14711-50021
226102
226101
226105
PART No.
1Hyd Hose, 4(3/4-16UNF)×4(3/4-16UNF) 450L(3/8)20
1Hyd Hose, 4(3/4-16UNF)×4(3/4-16UNF) 900L(3/8)21
1Hyd Hose, 4(3/4-16UNF)×2(3/4-16UNF) 450L(3/8)22
1Bar, Gauge-Long5
1Valve, Relife6
4Nipple, PF3/8, O-Ring×3/4-16UNF7
8Nipple, PF3/8, O-Ring×3/4-16UNF,Hose 90˚8
4Nipple, H-Type 3/4-16UNF,Hose9
12O-Ring, 1BP1410
1Pipe Ass'y11
1Pipe Ass'y12
1Pipe Ass'y13
1Pipe Ass'y14
1Pipe Ass'y15
1Pipe Ass'y16
1Pipe Ass'y17
1Pipe Ass'y18
1Pipe Ass'y19
I.C
1Hyd Hose, 4(3/4-16UNF)×2(3/4-16UNF) 900L(3/8)23
1Bar,Gauge-Short4
1Bucket Cylinder Ass'y-RH3
1Bucket Cylinder Ass'y-LH2
2Boom Cylinder Ass'y1
REMARKQ'tyDESCRIPTIONREF. NO
13
