Kioti KL155 - Page 84

PART ILLUSTRATIONS 13-25
802N2-P46F9-41
103C0-C0330
103E1-C0380
805BB-1P460
80620-06027
80620-24001
80620-25002
80620-26004
10321-M0600
10316-M0600
10211-M0602
10121-M0602-50
1012S-M0803-20
FTE11-H0120-01
FTE11-H0110-01
10211-M1004
10121-M1004-30
FTF40-62102
FTF40-62101
1012S-M0803-35
80620-03023
80620-01016
80620-01024
PART No.
4Nipple, PF3/843
8Seal Bond, 3/8"44
2Washer-Copper, 3/8"45
4Clamp28
1Clamp29
2Hex-Bolt, M10×1.5P 30L30
2Hex-Nut, M10×1.5P31
1Cover,Pipe32
1Cover Ass'y-Valve33
4Bolt-Sem's, M8×1.25P 20L34
2Hex-Bolt, M6×1.0P 50L35
2Hex-Nut, M6×1.0P36
2Washer-Spring, M1037
4Washer Plain, M638
1Hyd Hose, 2(3/4-16UNF)×45Benzo(PF3/8) 750L(3/8)39
1Hyd Hose, 2(3/4-16UNF)×Benzo(PF3/8) 750L(3/8)40
1Hyd Hose, 4(3/4-16UNF)×45Benzo(PF3/8) 600L(3/8)41
1Hyd Hose, 4(3/4-16UNF)×Benzo(PF3/8) 560L(3/8)42
I.C
2Nipple, PF3/8, Copper×3/4-16UNF, Hose46
11Bolt-Sem's, M8×1.25P 35L27
1Hyd Hose, 4(3/4-16UNF)×2(3/4-16UNF) 800L(3/8)26
1Hyd Hose, 4(3/4-16UNF)×4(3/4-16UNF) 800L(3/8)25
2Hyd Hose, 4(3/4-16UNF)×4(3/4-16UNF) 700L(3/8)24
REMARKQ'tyDESCRIPTIONREF. NO
