CONNECTING
1. Clean both couplers.
2. Remove dust plugs.
3. Insert the implement coupler to the
tractor hydraulic coupler.
4. Pull the implement coupler slight-
ly to make sure couplers are rmly
connected.
DISCONNECTING
1. First lower the attachment on the
ground to remove the hydraulic
pressure in the hose.
2. Clean the couplers.
3. Relieve pressure by moving hydrau-
lic control levers with engine shut
off. Pull the hose straight from the
hydraulic coupler to release it.
4. Clean oil and dust from the coupler,
then replace the dust plugs.
COUPLER CONNECTING AND
DISCONNECTING
Pull
Out
In
Push
In
Out
Port
A
B
Lever
Pressure Returning
Move the lever up or down and hold.
This will raise or lower the implement.
Lever will return to neutral when re-
leased.
Port A, B
Coupler Size
PT 1/2”
Do not hold the lever in the
“pull” or “push” position
once the remote cylinder has
reached the end of the stroke,
as this will cause oil to flow
through the relief valve.
To enlarge the front loader out-
put, when using the hydraulic
system of the tractor, do not op-
erate the boom and the bucket
cylinder simultaneously.
IMPORTANT
To avoid personal injury:
Stop the engine and relieve
pressure before connecting or
disconnecting lines.
Do not use your hand to check
for leaks.
CAUTION
Your local KIOTI Dealer can
supply parts to adapt couplers
to hydraulic hoses.
NOTE
