K110sm4e1.doc
4-6
4. 5 Switch, Inlet
Item Name Type Function
17 Power Switch AJ7201BF Supplies / shuts AC power.
18 AC Inlet FN9222R-3-06 Receives AC power.
19 USB Terminal
17 18 19
