5. 1. 5 Removing Front Covers
1. Remove Top Cover, Side Cover L and Operation Panel Assembly.
See [5.1.1 Removing Top Cover], [5.1.3 Removing Side Cover L], and [5.1.4 Removing
Operation Panel Assembly].
2. Remove Original Guides (1).
3. Remove 6 screws (2: 4x6) and remove Original Table (3).
1
2
3
2
