Chapter 2 Basic Operation 2-15
7. Turn the body (4) of the cartridge in two or more revolution to the arrow direction to open the
toner supply hole. Confirm that the projection (8) if fitted into the notch (9).
8. Close the Toner Hatch (1).
NOTE
It is not necessary to lock the cartridge with the
Lever (2). Lever (2) will engage on its own after
closing the Toner Hatch.
4
8
9 9
8
2
1
To Next Page
