KIP 75 Series - Roll Deck Section Jam (Deck 1, 2, 3, 4 Mis-Feed)

Chapter 3 Error Correction 3-3
3. 1. 1 Roll Deck Section Jam (Deck 1, 2, 3, 4 Mis-feed)
1. Pull the blue lever (1) to unlock the Roll Deck. Draw out the Roll Deck.
2. Rewind the roll media.
Roll Deck Section
- Deck 1 Mis-feed
- Deck 2 Mis-feed
1
- Deck 3 Mis-feed
- Deck 4 Mis-feed
