WARNING
Always make a pre-operation inspection before you start the engine.
Know how to stop the generator quickly and understand operation of all
the controls. Never permit anyone to operate the generator without proper
instruction.
Keep children and pets away from the generator when it is in operating.
Keep away from rotating parts while the generator is running.
The generator is a potential source of electrical shocks when misused; do
not operate with wet hands.
Place the generator at least three feet or one meter away from buildings or
other equipment during operation.
Operate the generator on a level surface to prevent fuel spillage and oil
starvation.
the
Do not operate the generator in rain or snow or
allow it to get wet.
-2- -23-
10. SPECIFICATIONS
DC output
DC voltage
Electric circuit breaker
Phase number
12V-8.3A
Without
Single
SPECIFICATIONS
Model
IG6000/IG6000h
Rated frequency (Hz)
Rated voltage (V)
Rated current (A)
Rated output (Watts)
Max output (Watts)
5500
6000
Engine
Model Type
KG390Gi
Type
Displacement (Bore Stroke)
Compression ratio
Rated power [kW(hp)/(r/min))]
Rated rotation speed (rpm)
Ignition system
Spark plug
Starting system
Fuel
Lube oil
Lube oil capacity
Single cylinder, 4 stroke, vertical, air-cooled, OHV, gasoline engine
23.7 cu. In. (389 cc)
8.5:1
7.7/3600
3600
T. C. I
WR7DC
Electric starter/manual recoil
Automotive unleaded gasoline, 87 octgane
SAE 10W30 (above CC grade)
1.2 qt. (1.1L)
Fuel tank capacity (L)
Continuous running time at rated output
Noise level(zero load~ full load) @ 23' (7M)
5.8gal.(22L)
7.5 Hours
64-65 decibels
Dry weight -lbs(kg)
IG6000: 95 (209) IG6000h: 115(263)
60
120/240
45.8/22.9
Overall dimension (L W H) in. (mm)
IG6000: 31.6 19.5 24.6(802 495 624)
IG6000h: 49.3 19.9 30.3(235 650 770)
