Kipor Sinemaster IG3000 User Manual

13
(3) Insert the engine key and turn the engine switch to ON position.
See fig.10
Fig.10 Starting button to the ON position
(4) Starting
Electric start: Pull the engine switch to the START until the engine is started. See
fig.11 (a)
Manual start: Pull the starting handle until resistance is felt. Pull quickly in the
direction showed in the following diagram. See fig.11 (b).
Fig.11 (a) Engine Fig.11 (b) Starting handle
CAUTION
■ Keep the starting handle from rebounding and slowly put the handle in order.
■ Keep the starting handle away from rubbing generator or handle would be
damaged.

Kipor Sinemaster IG3000 Specifications

General

Rated Power	2.8 kW
Maximum Power	3.0 kW
Max. AC Output	3.0 kVA
Rated Voltage	230 V
Rated Frequency	50 Hz
Power Factor	1.0
Engine Type	4-stroke, OHV, single cylinder
Displacement	196 cc
Fuel Type	Unleaded Gasoline
Fuel Tank Capacity	13 L
Starting System	Recoil start
Noise Level	65 dB at 7 m
