Kipor Sinemaster IG3000 User Manual

12
4. Starting engine
CAUTION
■ When starting the generator after adding fuel for the first time, after long-term
storage, or after running out of fuel, turn the fuel valve lever to the "ON" position,
then wait for 10 to 20 seconds before starting the engine.
4.1 IG3000 starting order:
(1) Open the fuel valve first, see fig.8.
Fig.8 Fuel valve lever to the ON position
(2) Pull the choke knob out to the CLOSED position
Do not use the choke when the engine is warm or the air temperature is high, see
fig.9
Fig.9 Choke knob to the closed position

Kipor Sinemaster IG3000 Specifications

General

Rated Power	2.8 kW
Maximum Power	3.0 kW
Max. AC Output	3.0 kVA
Rated Voltage	230 V
Rated Frequency	50 Hz
Power Factor	1.0
Engine Type	4-stroke, OHV, single cylinder
Displacement	196 cc
Fuel Type	Unleaded Gasoline
Fuel Tank Capacity	13 L
Starting System	Recoil start
Noise Level	65 dB at 7 m
