Kipor Sinemaster IG3000 User Manual

29
(2)Parameters of IG4000：
Model IG4000
Rated frequency（Hz） 50 60
Rated voltage（V） 230 120 240
Rated current（A） 16.5 31.7 15.9
Rated rotation speed（r/min） 3600
Rated output power（kVA） 3.8
Max. output power（kVA） 4.2*
DC output
DC output 12V-5.0A
Fuse Available
Phase number Single
Engien
Model KG280GETi
Type
Single-cylinder, oblique, air-cooled,
four-stroke, OHV
Displacement（Bore x stroke） 277ml（78×58 mm）
Compression ratio 8.5:1
Rated frequency [kW/（r/min）] 5.5/3600
Rated rotation speed（rpm） 3600
Ignition system T.C.I
Spark plug WR7DC
Starting system Recoil starter, electric starter
Fuel type Automotive unleaded gasoline
Fuel consumption（g/Kw.h） 374
Lube oil brand SAE 10W30（Above CC Grade）
Fuel capacity（L） 13.0
Continuous running time(hr) (rated output) 5
Noise level(dB(A)/7m(zero load-full load) 65-73 **
Overall dimension（Length×Width×height）[(mm)]
IG4000:785×470×570
(30.9×18.5×22.44)
Dry weight[kg(lbs)] IG4000:75（165）
*: After 20 hours' running-in period
**: The declared values shall consider uncertainties due to production variation and
measurement procedures.

Kipor Sinemaster IG3000 Specifications

General

Rated Power	2.8 kW
Maximum Power	3.0 kW
Max. AC Output	3.0 kVA
Rated Voltage	230 V
Rated Frequency	50 Hz
Power Factor	1.0
Engine Type	4-stroke, OHV, single cylinder
Displacement	196 cc
Fuel Type	Unleaded Gasoline
Fuel Tank Capacity	13 L
Starting System	Recoil start
Noise Level	65 dB at 7 m
