Kipp & Zonen SMP series User Manual

68 mm
Ø50 mm
33
.
Kipp & Zonen reserves the right to make changes to specifications and other product documentation without prior notice.
7.1 Optical and electrical
7.2 Dimensions and weight
SMP3 SMP’s (except SMP3 and SMP11) SMP11
Weight without cable: 0.3 kg Weight without cable: 0.6 kg Weight without cable: 0.6 kg
68 mm
Ø32 mm
Ø110 mm
68 mm
Ø50 mm
Ø150 mm
Ø150 mm Ø150 mmØ150 mm
7. Specifications
Classification to ISO 9060:1990
Analogue output • V-version
Analogue output range*
Analogue output • A-version
Analogue output range*
Serial output
Serial output range
Response time
(63%)
Response time (95%)
Spectral range (20% points)
Spectral range (50% points)
Zero osets (unventilated)
(a)
thermal radiation (at 200 W/m)
(b)
temperature change (5 K/h)
Non-stability (change/year)
Non-linearity (100 to 1000W/m)
Directional response
(up to 80° with 1000W/m beam)
Temperature response
Spectral selectivity
(350 to 1500nm)
Tilt response (0° to 90 ° at 1000W/m)
Field of view
Accuracy of bubble level
Power consumption
(at 12VDC)
Supply voltage
Detector type
Operating and storage temperature range
Humidity range
MTBF
(Mean Time Between Failures) **
Ingress Protection (IP) rating
Soware, Windows™
Specifications
Second Class
0 to 1V
-200 to 2000W/m
4 to 20mA
0 to 1600W/m
RS-485 Modbus®
-400 to 2000W/m
< 1.5s
< 12s
285 to 3000nm
300 to 2800nm
< 15W/m
< 5W/m
< 1%
< 1.5%
< 20W/m
< 2%
(-20°C to +50°C)
< 4% (-40 °C to +70 °C)
< 1%
< 1%
180°
< 0.2°
V-version: 55mW
A-version: 100mW
5 to 30VDC
Thermopile
-40°C to +80 °C
0 to 100%
> 10 years
67
Smart Sensor Explorer Soware, for configuration, test and data logging
SMP3
First Class
0 to 1V
-200 to 2000W/m
4 to 20mA
0 to 1600W/m
RS-485 Modbus®
-400 to 2000W/m
< 1.5s
< 12s
270 to 3000nm
285 to 2800nm
< 10W/m
< 4W/m
< 1%
< 1%
< 15W/m
< 1.5%
(-20°C to +50°C)
< 3% (-40 °C to +70 °C)
< 1%
< 1%
180°
< 0.1°
V-version: 55mW
A-version: 100mW
5 to 30VDC
Thermopile
-40°C to +80°C
0 to 100%
> 10 years
67
SMP6
Secondary Standard
0 to 1V
-200 to 2000W/m
4 to 20mA
0 to 1600W/m
RS-485 Modbus®
-400 to 4000W/m
< 0.7s
< 2s
270 to 3000nm
285 to 2800nm
< 7 W/m
< 2 W/m
< 0.5%
< 0.2%
< 10 W/m
< 1%
(-20°C to +50°C)
< 2% (-40 °C to +70 °C)
< 1%
< 0.2%
180°
< 0.1°
V-version: 55mW
A-version: 100mW
5 to 30VDC
Thermopile
-40°C to +80 °C
0 to 100%
> 10 years
67
SMP10 and SMP11
Secondary Standard
0 to 1V
-200 to 2000W/m
4 to 20mA
0 to 1600W/m
RS-485 Modbus®
-400 to 4000W/m
< 0.7s
< 2s
270 to 3000nm
285 to 2800nm
< 7 W/m
< 2 W/m
< 0.5%
< 0.2%
< 10W/m
< 0.3%
(-20°C to +50°C)
< 0.3% (-40°C to +70°C)
< 1%
< 0.2%
18
0°
< 0.1°
V-version: 55mW
A-version: 100mW
5 to 30VDC
Thermopile
-40°C to +80 °C
0 to 100%
> 10 years
67
Secondary Standard
0 to 1V
-200 to 2000W/m
4 to 20mA
0 to 1600W/m
RS-485 Modbus®
-400 to 4000W/m
< 0.7s
< 2s
210 to 3600nm
250 to 3500nm
< 3 W/m
< 1 W/m
< 0.5%
< 0.2%
< 5 W/m
< 0.3%
(-20°C to +50°C)
< 0.3% (-40°C to +70°C)
< 2%
< 0.2%
180°
< 0.1°
V-version: 55mW
A-version: 100mW
5 to 30VDC
Thermopile
-40°C to +80 °C
0 to 100%
> 10 years
67
SMP21 SMP22
** extrapolated aer introduction in January 2012
Note: The performance specifications quoted are worst-case and/or maximum values
* adjustable with Smart Explorer Soware
Instrument accuracy

Kipp & Zonen SMP series Specifications
