Error reports
PDU address Parameter R/W
(2)
Type Mode Description
26 IO_ERROR_CODE R U16 All Most recent/ actual error code
27 IO_PROTOCOL_ERROR R U16 All Protocol error/communication error
28 IO_ERROR_COUNT_PRIO1 R U16 All Error code priority 1
29 IO_ERROR_COUNT_PRIO2 R U16 All Error count priority 2
30 IO_RESTART_COUNT R U16 All Number of controlled restarts
31 IO_FALSE_START_COUNT R U16 All Number of uncontrolled restarts
32 IO_SENSOR_ON_TIME R U16 All On time in seconds (MSB word)
33 IO_SENSOR_ON_TIMEL R U16 All On time in seconds (LSB word)
41 IO_BATCH_NUMBER R U16 All Production batch number
42 IO_SERIAL_NUMBER R U16 All Serial number
43 IO_SOFTWARE_VERSION R U16 All Software version
44 IO_HARDWARE_VERSION R U16 All Hardware version
45 IO_NODE_ID R U16 All (MODBUS®/SMA) device address RS-485
(2)
Writing any value to input registers 26-33 will reset the contents of the registers
Legend
PDU address PDU address + 1 = Modbus® register number
Parameter Name Name of the register
R/W Read write R Read only
R/W Read/write
Type Type and size U16 16 bit unsigned integer
S16 16 bit signed integer
S32 32 bit signed integer (MSB first, LSB last)
Mode Operation mode N available in normal mode
S available in service mode
C available in calibration mode (not for users)
F available in factory mode (not for users)
All available in all modes
Real-time Data A/D Counts
PDU address Parameter R/W Type Mode Description
18 IO_ADC1_COUNTS R S32 All Input voltage sensor 1 in 0.01 V
19 (R18=MSB, R19=LSB)
20 IO_ADC2_COUNTS R S32 All Not supported, always 0
21
22 IO_ADC3_COUNTS R S32 All Input voltage body temperature sensor in 0.01 V
23 (R22=MSB, R23=LSB )
24 IO_ADC4_COUNTS R S32 All Input voltage power sensor in 0.01 V
25 (R24=MSB, R25=LSB)
