KIRLOSKAR CPHM - Bearing and Lubrication Information

IOM/CPHM/DEC19/01 ISSUE DATE:14-12-2019
Page 9 | 48 REVISION NO.1
Sr.
No.
Pump Type Water Fill
Capacity
(Litres)
Weight
(kg
approx.)
Max.
solid
size
(mm)
Max.
Rotational
Speed
(rpm)
37
CPH
M 150/3
2
18.
0
221
2
3.0
1500
38
CPHM 150/32N
18.0
221
23.0
1500
39
CPHM 65/43
10.0
195
15.0
1500
40
CPHM 80/40
11.0
124
8.0
1500
41
CPHM 80/40N
11.0
124
8.0
1500
42
CPHM 100/40
13.8
134
11.0
1500
43
CPHM 125/40
15.5
180
13.0
1500
44
CPHM 125/40N
15.5
180
13
.0
15
00
45
CPHM 200/38M
25.5
550
26.0
1500
46
CPHM 200/46
27.5
560
26.0
1500
47
CPHM 125/45
17.0
290
14.0
1500
48
CPHM 150/40
15.5
285
14.0
1500
49
CPHM 150/43
21.0
300
14.0
1500
50
CPHM 150/52
22.0
435
15.0
1500
NOTE:
Please contact the supplier or manufacturer if the pump is to be used for other
than the specified speeds.
4.3 Bearings and Lubrication
4.3.1 Specifications of bearings, oil seals and felt rings.
PART
No.
DESCRIPTION
UNIT
-
5
UNIT
-
7
UNIT
-
9
UNIT
-
11,11A
,11B
UNIT
-
11B
UNI
T
-
13,13A
50
2.1
Fel
t ring (DE)
25 x 38 x 6T
43 x 30 x 6T
40 x 53 x
6T
-
-
502.2
Felt ring (NDE)
25 x 38 x 6T
35 x 47 x 5T
45 x 58 x
6T
-
-
500.1
Oil Seal (DE)
25 x 37 x 7T
32 x 45 x 7T
72 x 42 x
10T
72 x 50 x
10T
72 x 50 x
10T
60 x 85 x
13T
500.2
Oil
Seal (N
DE)
2
5 x 37
x 7T
32 x 47 x 7T
60 x 45 x
8T
72 x 50 x
10T
72 x 50 x
10T
65 x 85 x
13T*
