IOM/KPDS/NOV 19/00
Page 1
11
1 of 50
5050
50
Issue Date : 22/11/2019
Revision: 00
1. INTRODUCTION:
Purpose of this manual
The purpose of this manual is to provide necessary information for:
•
Installation
•
Operation
•
Maintenance
CAUTION:
•
Read this manual carefully before installing and using the product. Improper
use of the product can cause personal injury and damage to property, and
may void the warranty.
NOTICE:
•
Save this manual for future reference, and keep it readily available at the
location of the unit.
Product Description: -
1.1 ‘KIRLOSKAR’ make KPDS - KPDSQF pumps are used for handling various types of
chemical liquids like acids, alkalis, hazardous liquids, hydrocarbons and water.
These pumps are manufactured to close tolerance and are of rigid construction,
However, proper installation, operation and maintenance are equally important to
ensure trouble free service. This booklet covers important guidelines and
instructions for installation, operation and maintenance. These instructions should
be followed carefully for satisfactory performance of the pumping unit. Only
mechanical aspects are dealt within this booklet.
1.2 This booklet covers instructions for following types of KPDS and KPDSQF series.
Unit 80C25
Unit 100C25 Unit 150C38
Unit 150C45
(1450RPM only)
20/13QF 25/16QF 25/26A# 65/32*
20/16QF 32/13* 32/26* 80/32*
20/20QF 32/16* 40/26* 80/40*/80/40N#
32/16A# 40/32* 100/26#
32/20* 50/26* 100/32*
32/20A# 50/32* 100/40*
40/13* 65/16* 125/26*
40/16* 65/20* 125/32*
40/20*,40/20A#
65/26* 125/40#,125/45#
50/13* 65/26N# 125/40N#
50/16* 80/16* 150/32*,150/32N#
50/16A# 80/20* 150/40#
50/20* 80/26* 65/43#
65/13* 100/20*
NOTES:
a) *Marked pumps are also supplied with semi-open (QF) type impeller as an
option.
