Hexagon socket head cap screw ⑪
Worm shaft ⑨
Hexagon socket head cap screw ⑦
Reference plane for horizontal installation
Hexagon socket headless tapered pipe plugs ⑥
（at vertical installation）
Motor case ①
Base ⑩
Reference plane for vertical
Installation Hexagon socket
headless tapered pipe plugs ⑤
（at horizontal installation）
O-ring ④
Hexagon socket head cap screw ③
Coupling ⑧
Motor ②
Fig.5
