37
○ Accessory
MARK NAME
MR(M)
120
MR(M)
160
MR(M)
200
MR(M)
250
MR(M)
320
MX(M)
160
Q'ty Recital
91 Eye bolt M8 M10 M12 M10 2
92 Eye bolt M8 M10 M12 M10 1
93
Hexagon
head bolt
M12x45
(2)
M16x55
(2)
M16x50
(2)
M16x65
(4)
M16x75
(4)
M16x55
(2)
(*)
Strength
Dimension
8.8
94 Washer
12
(2)
16
(2)
16
(4)
16
(2)
(*)
95 Clamp － － 4
96 T-slot nut
1412
(2)
1816
(2)
1816
(4)
1816
(2)
(*)
When the specification is different, the clamping parts and guide block are different from
the above figure. For detailed models, refer to attached outside view.
