Parts List
104
No. Part (Description)
Warranty
coverage
(year)
QTY No. Part (Description)
Warranty
coverage
(year)
QTY
1A Main lid 3 1 36A Control Knob B (small) 1 1
2A Main lid screw 1 2 37A Main burner 10 5
3A Temperature gauge housing 1 1 38A Main burner igniter wire A 1 1
4A Temperature gauge 1 1 39A Main burner igniter wire B 1 1
5A Main lid handle assembly 3 1 40A Main burner igniter wire C 1 1
6A LED light switch 1 1 41A Main burner igniter wire D 1 1
7A LED light 1 1 42A Main burner igniter wire E 1 1
8A Rotisserie burner heat shield 1 1 43A Burner pin assembly 1 5
9A
Rotisserie burner rear cover
1 1 44A Flame tamer 3 5
10A Rotisserie burner igniter wire
1
1 45A Grease cup 1 1
11A Rotisserie burner igniter bracket
1
2 46A Cooking grid with hole 3 3
12A
Rotisserie burner orifice w/brass
elbow
1
1 47A Warming rack 3 1
13A Rotisserie burner
1
1 48A Foldable side shelf, left 3 1
14A Rotisserie burner flex gas line 1 1 49A Foldable side shelf Bracket A 3 1
15A Main burner bowl assembly
Non-
replaceable
1 50A Foldable side shelf Bracket B 3 1
16A Main bowl assembly flange, left
1
1 51A Side shelf, left 3 1
17A Main bowl assembly flange, right 1 1
52A
Cart trim piece , left
3 1
18A Main burner bowl supporter, rear 1 1 53A Cart frame assembly, left 1 1
19A Main firebox trim piece, left 3 1 54A Electric igniter module 1 1
20A Main firebox trim piece, right 3 1 55A Electric igniter module heat shield 1 1
21A Firebox trim piece 3 1 56A Faux stone side panel, left 1 1
22A
Firebox heat shield 1 1
57A Battery box 1 1
23A
Front baffle 1 1
58A Faux stone front panel, left 1 1
24A
Front baffle bracket
1 1
59A Door, left 3 1
25A
Gas quick connector 1 1
60A Door hinge 1 4
26A Main manifold 1 1 61A Door handle assembly 3 2
27A Igniter junction wire 1 1 62A Swivel caster 1 1
28A Rotisserie gas valve 1 1
63A
Swivel caster with brake 1 1
29A Main gas valve 1 5 64A Caster 1 2
30A Regulator, LP 1 1 65A Door magnet heat shield panel 1 1
31A Main control panel 3 1 66A Door stopper 1 1
32A Logo 1 1 67A Door magnet 1 4
33A Bezel A 1 5 68A Door magnet plate A 1 1
34A Bezel B (small) 1 1 69A Bottom panel 1 1
35A Control knob A 1 5 70A Leveling feet adjusted handle 1 4
