Change The Sear Burner Orifice
1. Disconnect the quick connector.
2. Set the lock bar in unlock position.
3. Use a screwdriver to remove screw from the igniter pin
and two screws on the rear of the searing burner.
4. Lift the burner starting from the back, as shown.
9. Reinstall the rotisserie burner rear cover.
10. Reinstall the six screws onto the rotisserie burner rear
cover.
11. Reinstall the rotisserie burner heat shield.
12. Tighten the two screws.
28
