No. Part (Description)
Warranty
coverage
(Year)
QTY No. Part (Description)
Warranty
coverage
(Year)
QTY
1 Main Lid 3 1 35 Grease box 1 1
2 Main Lid screw 3 2 36 Door hinge 1 4
3 Temperature gauge housing 1 1 37 Door handle seat 1 4
4 Temperature gauge 1 1 38 Door handle tube 1 2
5 Main lid handle seat, left 1 1 39 Door, left 3 1
6 Main lid handle tube 1 1 40 Door, right 3 1
7 Main lid handle seat, right 1 1 41 Lighting rod 1 1
8 Warming rack 1 1 42 Lighting rod cover 1 1
9 Cooking grid with hole 3 3 43 Gas tank tray slide 1 2
10 Flame tamer 1 4 44 Tank tray bolt 1 1
11 Main burner 10 4 45 Gas tank tray block piece 1 1
12 Main burner igniter wire A 1 1 46 Gas tank tray slide bracket, left 1 1
13 Main burner igniter wire B 1 1 47 Tank tray 1 1
14 Main burner igniter wire C 1 1 48 Gas tank tray slide bracket, right 1 1
15 Main burner igniter wire D 1 1 49 Electric igniter module 1 1
16 Main lid bracket, right 1 1 50 Bottom panel 1 1
17 Burner pin assembly 1 4 51 Swivel caster with brake 1 1
18 Main lid bracket, left 1 1 52 Swivel caster 1 1
19 Regulator, LP 1 1 53 Door hinge bracket 1 4
20 Front baffle 1 1 54 Side panel, left 1 1
21 Igniter junction wire 1 1 55 Rubber grommet 1 1
22 Main Gas valve 1 4 56 Back panel 1 1
23 Main manifold 1 1 57 Caster 1 2
24
Side burner orifice brass
connector
1 1 58 Side panel, right 1 1
25 Side burner flex gas line A 1 1 59 Side burner control panel, right 1 1
26 Side manifold 1 1 60 Side burner igniter wire 1 1
27 Side burner gas valve 1 1 61 Main burner bowl assembly
non-
replaceable
1
28 Side burner flex gas line B 1 1 62 Side burner 1 1
29 Logo 1 1 63 Side burner bowl assembly 1 1
30 Main control panel 1 1 64 Hooks 1 6
31 Control knob 1 5 65 Side burner end cap 1 1
32 Bezel 1 4 66 Side burner cooking grid 3 1
33 Cart frame, front 1 1 67 Side burner lid 1 1
34 Door magnet 1 2 68 Side burner lid hinge rod pin 1 4
