KitchenAid 720-0745A (LP) - Page 10

10
Part
Number
Part (description) Warranty
Coverage
Quantity
01 Main lid 3 1
02 Main lid screw 3 2
03 Temperature gauge
housing
1 1
04 Temperature gauge 1 1
05 Logo 1 1
06 Main lid handle seat, left 1 1
07 Main lid handle seat, right 1 1
08 Main lid handle tube 1 1
09 Rear baffle 1 1
10 Rotisserie burner ignition
wire
1 1
11 Rotisserie heat shield 1 1
12 Rotisserie burner 1 1
13 Rotisserie burner igniter
bracket
1 2
14 Rotisserie burner flex gas
line
1 1
15 Rotisserie burner with
brass elbow
1 1
16 Main lid bracket, left 1 1
17 Main lid bracket, right 1 1
18 Front baffle 1 1
19 Regulator, LP 1 1
20 Sear gas valve 3 1
21 Side manifold 1 1
22 Side burner flex gas line 1 1
23 Rotisserie gas valve 3 1
24 Main manifold 1 1
25 Igniter junction wire 1 1
26 Main gas valve 3 4
27 Main control panel 3 1
28 Light switch 1 1
29 Control knob 1 5
30 Bezel 1 5
31 Control knob bezel,
rotisserie burner
1 1
32 Control knob, rotisserie
burner
1 1
33 Cart frame, front 1 1
34 Door magnet 1 2
35 Push bar, side shelf 3 1
36 Side shelf, left 3 1
37 Side shelf front panel, left 3 1
38 Rubber grommet 1 3
39 Side panel, left 3 1
40 Door hinge bracket 1 4
41 Swivel caster with brake 1 1
42 Swivel caster 1 1
43 Caster 1 2
44 Bottom panel 1 1
45 Tank tray 1 1
46 Gas tank tray slide
bracket, left
1 1
47 Gas tank tray slide
bracket, right
1 1
48 Gas tank tray slide 1 2
49 Tank tray bolt 1 1
50 Gas tank tray block piece 1 1
51 Cart basket 1 1
52 Grease box 1 1
53 Door hinge 1 4
54 Door handle seat 1 4
55 Door handle tube 1 2
56 Door, left 3 1
57 Door, right 3 1
58 Lighting rod 1 1
59 Lighting rod cover 1 1
60 Electric igniter module 1 1
61 Side panel, right 3 1
62 Cable strainer securing
plate
1 1
63 Cable strainer 1 1
64 Back panel 3 1
65 Igniter wire cover 1 1
66 Side burner control panel,
right
3 1
67 Side burner bowl
assembly
1 1
68 Side burner grease tray 1 1
69 Sear burner 1 1
70 Sear burner igniter wire 1 1
71 Sear burner cooking grid
with hole
3 1
72 Side burner lid 3 1
73 Side burner lid hinge rod 1 2
74 Transformer 1 1
75 Lamp cord 1 1
76 Lamp 1 2
77 Lamp case 1 1
78 Main burner igniter wire A 1 1
79 Main burner igniter wire B 1 1
Part
Number
Part (description) Warranty
Coverage
Quantity
