ChangeGrillRotisserieBurnerOrifices
1. Using a Phillips screwdriver, unscrew the 2 screws and
remove the rotisserie burner heat shield.
2. Using a Phillips screwdriver, remove the 6 screws at the
back of grill from inside the grill (3 screws on each side of
the rotisserie burner).
5. Re-Insert the searing main burner and lock all removed
screws.
21
5. Use 24 mm wrench to remove the orifice nut.
3. Remove the access cover at the back of the grill.
6. Take out the orifice support, and then use a 6 mm socket
and wrench or 6 mm nut driver to remove the LP orifice at
the end of the supply pipe. Replace with Natural gas
orifice.
A. Orifice Support
B. Orifice
4. Using a Phillips screwdriver, remove the screws holding the
spider guard to the burner.
A
A. Access Cover
A
A. Orifice Nut.
A
B
IMPORTANT: Check that the orifice is properly installed inside
of supply pipe.
