KitchenAid 720-0891B - Installation Instructions

A
x12
B x21
Hardware package list
Tools Needed
C
x32
D x16
Truss head screw
with locking washer
1/4" x 15mm
SUS Screw
5/32" x 10mm
Flat Washer
1/4"
Truss Head Screw
1/4" x 12mm
Some parts come with Screws pre-installed.
Loosen and tighten for final assembly.
11
ASSEMBLY INSTRUCTIONS
