INSTALLATION INSTRUCTIONS
Unpack Grill
Unpack Grill
1. Remove all packaging materials and remove grill from the shipping
base.
2. Move grill close to desired outdoor location.
3. Open the grill hood.
4. Using an utility knife to cut yellow straps and packing tape to open
box from top and remove the boxes.
5. Remove the warming shelf and grill grates from inside the grill and
remove the package inside the firebox.
6. Remove foam block and wrap from inside the grill.
7. Replace the grill grates.
8. Place warming shelf on brackets as shown.
9. Dispose of/recycle all packaging material.
Install 20
lb LP
Gas Fuel T
a
nk Tray
The tank tray should be secured to a fixed location that can be easily
accessed and will allow the gas pressure regulator/hose assembly to
connect to the 20 lb LP gas fuel tank without kinking or putting strain on
the gas pressure regulator/hose assembly.
1. Place the tank tray in a location that can be secured using
4 screws (supplied) through the predrilled holes.
2.
Use 4 screws to secure the tank tray. T
he typical location for a 20 lb
LP gas fuel tank is within the enclosure where the tank can be turned
on and off easily.
A. Warming rack brackets
B. Warming rack
Excessive Weight Hazard
Use two or more people to move and install grill.
WARNING
Failure to do so can result in back or other injury.
A
