INSTALLATION REQUIREMENTS
Tools and Parts
Gather these required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
Location Requirements
Read
and
follow
the
instructions
provided
with
any
tools
listed
here.
Tools needed
 Phillip screwdriver
 Wrench or pliers
 Pipe wrench
 Scissors or cutting pliers
(to remove tiedowns)
 Noncorrosive leak-
detection solution
Parts Supplied
 Gas pressure regulator/hose assembly set for 11” WCP LP
gas
 Right side shelf with sear burner
 Left side shelf
 Sear burner control knob
 “AA” Battery (1)
detection
solution
 Warming rack
 Cooking grid
 Side burner cooking grid
 Natural gas orifice for sear burner
Parts Needed
 20 lb LP gas fuel tank-approximately 18” (45.7cm) height.
Parts Needed for Conversion to Natural Gas
Parts
Needed
for
Conversion
to
Natural
Gas
 Natural gas conversion kit Part Number 710-0003. See
“Assistance” section to order. The conversion kit includes:
 Natural gas regulator 4" W.C. (marked “Natural Gas
Regulator”)
 10 ft (3.0 m) Natural gas hose with quick connector
 5.9" (150 mm) Natural gas regulator hose
 6 mm nut driver

6 mm wrench
Select a location that provides minimum exposure to wind
and traffic paths. The location should be away from strong
draft areas

6
mm
wrench
 Hex key
 Gas line shutoff valve
 1/2" male pipe thread nipple for connection to pressure
regulator.
 LP gas-resistant pipe-joint compound
 CSA design-certified outdoor flexible stainless steel
appliance connector (4-5 ft [1.2-1.5 m]) or rigid gas supply
line as needed.
draft
areas
.
Do not obstruct flow of combustion and ventilation air.
Clearance to combustible construction for grill:
 A minimum of 24” (61 cm) must be maintained between
the front of the grill hood, sides and back of the grill
and any combustible construction.
 A 24” (61 cm) minimum clearance must also be
maintained below the cookin
g
surface, and the
g
rill
gg
shall not be used under overhead combustible
construction.
Rotisserie (accessory – not included)*
If you equip your grill with a rotisserie, a 6" (15.2 cm)
minimum clearance is needed for the rotisserie motor.
A grounded, 3-prong outlet located to the left of the grill is
required.
*
See
“
Assistance
”
section to order.
5
See
Assistance
section
to
order.
