Custom Overlay Panels
(36" [91.4 cm] French Door Models)
Custom Backer Panels
(36" [91.4 cm] French Door Models)
34
17
⁄
32
"
(87.7 cm)
17
1
/
6
"
(43.3 cm)
17
1
/
6
"
(43.3 cm)
34
17
⁄
32
"
(87.7 cm)
7¹⁄₄"
(18.4 cm)
51
3
⁄
8
"
(130.5 cm)
51
3
⁄
8
"
(130.5 cm)
20
7
⁄
16
"
(51.9 cm)
TOP GRILLE PANEL
Maximum Weight: 10 lbs (4.5 kg)
FREEZER DOOR PANEL
Maximum Weight: 25 lbs (11.4 kg)
REFRIGERATOR
DOOR PANEL
Maximum Weight:
30 lbs (13.5 kg)
REFRIGERATOR
DOOR PANEL
Maximum Weight:
30 lbs (13.5 kg)
33
23
/ 32 "
(85.6 cm)
6
1
/ 4 "
(15.9 cm)
Bottom Offset
1
/ 2 " (1.27 cm)
49
5
/ 16 "
(125.2 cm)
20
3
/ 32 "
(51.0 cm)
16
11
/ 16 "
(42.4 cm)
34
7
/ 32 "
(86.9 cm)
Bottom
Offset
5
/ 8 "
(1.6 cm)
49
5
/ 16 "
(125.2 cm)
Bottom
Offset
5
/ 8 "
(1.6 cm)
Bottom offset
3
/ 16 " (4.7 mm)
Exterior
Panel
extends
above
door.
Side Offset
7
/ 16 " (1.1 cm)
16
11
/ 16 "
(42.4 cm)
Side
Offset
3
/ 16 "
(4.7 mm)
Side
Offset
3
/ 16 "
(4.7 mm)
Side
Offset
5
/ 32 "
(4 mm)
