Custom Overlay Panel Dimensions
Custom Overlay Panels
(36" [91.4 cm] Single Door Models)
Custom Backer Panels
(36" [91.4 cm] Single Door Models)
34³⁄₄"
(88.27 cm)
7¹⁄₄"
(18.42 cm)
34³⁄₄"
(88.27 cm)
34³⁄₄"
(88.27 cm)
51¹⁄₈"
(129.86 cm)
20³⁄₄"
(52.71 cm)
TOP GRILLE PANEL
Maximum Weight: 10 lbs (4.5 kg)
FREEZER DOOR PANEL
Maximum Weight: 20 lbs (9.1 kg)
REFRIGERATOR DOOR PANEL
Maximum Weight: 50 lbs (23 kg)
33³⁄₄"
(85.73 cm)
6³⁄₁₆"
(15.72 cm)
Bottom Offset
³⁄₈" (9.5 mm)
49¹⁄₈"
(124.78 cm)
20³⁄₁₆"
(51.28 cm)
34¹⁄₄"
(87.00 cm)
34¹⁄₄"
(87.00 cm)
Bottom Offset
⁷⁄₁₆" (11.1 mm)
Bottom Offset
¹⁄₄" (6.35 mm)
Center
Backer
Panel
left to
right
Center
Backer
Panel
left to
right
Center
Backer
Panel
left to
right
