FREEZER DOOR AND BASKET PARTS
10
For Models: KBLC36FKB01, KBLC36FKS01
(Black) (Stainless Steel)
8198079
Illus. Part
No. No. DESCRIPTION
1 2188599 Freezer Door
Panel (Includes
Item 9)
2 2204525 Divider, Basket
3 2207429 Clamp, Divider
4 2207415 Nut, Crimp
5 488649 Screw
6 2005400 Filler, Foam
7 2221031 Spacer, Door
Edge − Side
8 2221033 Spacer, Door Edge
Top & Bottom
9 2188533 Door Gasket,
Magnetic
10 308544 Screw, 10−24 x 1/2
11 Handle, Door
2209095B Black
2005290 Stainless Steel
12 2204542 Roller
13 Skin, Door
2209106B Black
2005399 Stainless Steel
14 Screw, 8−15 x 1/2
8281252 Black
8281250 Stainless Steel
15 2207533 Bracket, Assembly
Freezer Basket
16 2209202 Plate, Handle
17 2005376 Basket, Upper
18 2174124 Pan, Ice Cube
19 2207454 Nut, Hex
20 2207471 Bushing
21 3400507 Screw
22 2006244 Basket, Freezer
Lower
24 2207576 Spacer
26 2207550 Roller
