KitchenAid KBLC36MHB01 - Page 14

REFRIGERATOR DOOR PARTS
14
For Model: KBLC36MHB01, KBLC36MHT01, KBLC36MHW01
(Black) (Biscuit) (White)
4398948
Illus. Part
No. No. DESCRIPTION
1 2005168 Refrigerator
Door (Includes
Item 9)
2 Skin, Door
2209105B Black
2209105T Biscuit
2209105W White
3 2005171 Hinge Assembly,
Top
4 2004520 Spacer−Hinge,
Top
5 489282 Screw,
10−32 x .750
6 2003985 Hinge Assembly,
Bottom
7 2005397 Filler, Foam
8 2006140 Spacer, Door Edge
Side
9 2188410 Door Gasket,
Magnetic
10 308544 Screw,
10−24 x .500
11 Handle, Door
2209095B Black
2209095T Biscuit
2209095W White
12 2005982 Gasket (2)
13 2003982 Spacer−Hinge,
Bottom
14 2207417 Spacer, Door Edge
Bottom
15 487052 Screw
16 2209202 Plate−Door,
Handle
17 2207440 Spacer, Door Edge
Top
18 2005482 Tube, Door
Shelf
19 2005417 Shelf, Door (2)
20 489276 Screw,
8−18 x .750
21 2005542 End Cap, Left
22 2005541 End Cap, Right
23 2006152 Tube, Door
Shelf (Gallon)
26 2005983 Door, Utility
Bin (2)
27 2006154 Door Shelf,
Gallon
28 2165792 Butter Tray
