2
KEY USAGE TIPS
Filtration system
Your dishwasher has the latest
technology in dishwasher filtration.
This filtration system minimizes
sound and optimizes water and
energy conservation while providing
superior cleaning.
The filter system consists of 2
parts, an upper filter assembly
and lower filter.
IMPORTANT: To avoid damage to dishwasher, do not operate your
dishwasher without filters properly installed. Be sure lower filter is
securely in place and upper filter assembly is locked into place. If
upper assembly turns freely, it is not locked into place.
Filter maintenance
The filters may need to be cleaned when:
Visible objects or soils are on upper
filter assembly.
Dishes feel gritty to the touch.
See “Filtration System” in the full User
Instructions for complete removal and
maintenance schedule.
IMPORTANT: Do not use a wire brush or
a scouring pad, etc., as they may damage
the filters.
Rinse filter under running water until soils are
removed. If you have hard to remove soils or
calcium deposits because of hard water, a soft
brush may be required.
P
U
S
H
D
O
W
N
&
T
U
R
N
L
O
C
K
U
N
L
O
C
K
Drying – Rinse aid is essential
You must use a drying agent such as a rinse aid for good drying
performance. Rinse aid along with the Heat Dry or ProDry™
option will provide best drying and avoid excessive moisture
in dishwasher interior.
SLIDE
RINSE AID
IMPROVES DRYING
CHECK
WITH DOOR
FULLY OPEN
Full
Add
Lock
Dispensers vary by model.
Energy efficiency
Energy efficiency is gained by extending cycle time and
reducing the amount of wattage and water used during
your dishwasher’s cycle. For exceptional cleaning, cycles
are longer due to the soak and pauses. Several models
contain an optical water sensor used to determine water
and energy consumption for great cleaning performance.
Efficient dishwashers run longer to save water and energy, just as
driving a car slower saves on gas. Your first cycle will run longer to
calibrate the optical water sensor.
Press Start/Resume every time you
add a dish
IMPORTANT: If anyone opens the door (such as, for
adding a dish, even during the Delay Hours option),
Start/Resume must be pressed each time.
Push door firmly closed within 4 seconds of pressing
Start/Resume. If door is not closed within 4 seconds,
the Start button LED will flash, an audible tone will be
heard, and cycle will not start.
Upper filter
assembly
Lower filter
Tip Over Hazard
Do not use dishwasher until completely installed.
Do not push down on open door.
Doing so can result in serious injury or cuts.
WARNING
GROUNDING INSTRUCTIONS
SAVE THESE INSTRUCTIONS
For a grounded, cord-connected dishwasher:
The dishwasher must be grounded. In the event of a
malfunction or breakdown, grounding will reduce the risk of
electric shock by providing a path of least resistance for
electric current. The dishwasher is equipped with a cord
having an equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with all local
codes and ordinances.
WARNING:
Improper connection of the equipment-
grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or service representative if
you are in doubt whether the dishwasher is properly
grounded. Do not modify the plug provided with the
dishwasher; if it will not fit the outlet, have a proper outlet
installed by a qualified electrician.
For a permanently connected dishwasher:
The dishwasher must be connected to a grounded metal,
permanent wiring system, or an equipment-grounding
conductor must be run with the circuit conductors and
connected to the equipment-grounding terminal or lead on
the dishwasher.

Other manuals for KitchenAid KDFE104DSS

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KitchenAid KDFE104DSS and is the answer not in the manual?

KitchenAid KDFE104DSS Specifications

General IconGeneral
Stylebuilt-in dishwashers
Colorstainless steel
Load Capacity14
Cycle Selectionsexpress wash, light/china, normal, prowash, rinse only, tough
Options/Settings4 hour delay, control lock, heated dry, hi temp wash, sani rinse
Noise level46 decibels
Control Typeelectronic
Delay Startyes
Child Lockyes
Load Sensoryes
Number of Racks2
Cycle Signalno
Water Filteryes
Food Disposerno
Sanitize Settingsno
Annual Energy Consumption260 kilowatt hours
Voltage120 volts
Current15 amperes
Weight and Dimensions IconWeight and Dimensions
Depth24.75 inches
