Range
A. Center rear left surface burner
B. Left rear surface burner
C. Center front left surface burner
D. Left front surface burner
E. Control panel
F. Oven vent
G. Gas regulator
(located in rear of range)
H. Door gasket
I. Bake element (not visible)
J. Pin connector
(located in rear of range,
for factory testing only)
K. Right rear surface burner
L. Center rear right surface burner
M. Right front surface burner
N. Center front right surface
burner
O. Electronic oven control display
P. Self-cleaning latch
Q. Broil element (not shown)
R. Oven rack
S. Model and serial number
(located on the right-hand side
oven trim)
