KitchenAid KDTM384ESS User Manual

15
Filtration System
(for models with EQ filtration system)
Your dishwasher has the latest technology in dishwasher filtration. This triple filtration system minimizes sound and optimizes water and
energy conservation while providing superior cleaning performance. Throughout the life of your dishwasher, the filter will require
maintenance to sustain peak cleaning performance.
It is very easy to remove and maintain the filters. The chart below shows the recommended cleaning frequency.
*Manufacturer's recommendation: This practice will conserve the water and energy that you would have used to prepare your dishes. This
will also save you time and effort.
Very Hard Water
If you have hard water (above 15 grains), clean your filter at least
once per month. Building up of white residue on your dishwasher
indicates hard water. For tips on removing spots and stains, see
“Troubleshooting” section.
Cleaning Instructions
IMPORTANT: Do not use wire brush, scouring pad, etc., as they
may damage the filters.
Rinse filter under running water until most soils are removed. If you
have hard-to-remove soils or calcium deposits from hard water, a
soft brush may be required.
The triple filter system consists of 2 parts, an upper filter
assembly and a lower filter.
■ The upper filter assembly keeps oversized items and
foreign objects, along with very fine food particles, out
of the pump.
■ The lower filter keeps food from being recirculated onto
your dishware.
The filters may need to be cleaned when:
■ Visible objects or soils are on the Upper Filter Assembly.
■ There is degradation in cleaning performance (that is,
soils still present on dishes).
■ Dishes feel gritty to the touch.
RECOMMENDED TIME INTERVALS TO CLEAN YOUR FILTER
Number of Loads
Per Week
If you wash
before loading
If you scrape and rinse
before loading
If you only scrape
before loading*
If you do not scrape or rinse
before loading
1-3 Once per year Once per year Twice per year Every two months
4-7 Once per year Once per year Twice per year Once per month
8-12 Once per year Twice per year Every three months Every two weeks
13-14 Once per year Twice per year Every three months Once per week
Upper Filter
Assembly
Lower Filter
Filter Removal Instructions
1. Turn the Upper Filter
Assembly ¼ turn counter-
clockwise and lift out.
2. Grasp the Lower Filter in
the circular opening, lift
slightly, and pull forward
to remove.
3. Clean the filters as
shown below.
To remove Upper Filter Assembly
L
O
C
K
U
N
L
O
C
K
P
U
S
H
D
O
W
N
&
T
U
R
N

KitchenAid KDTM384ESS Specifications

General

Style	built-in dishwashers
Color	stainless steel
Load Capacity	15
Number of Cycles	6
Cycle Selections	express wash, light/china, normal, prowash, rinse only, tough
Options/Settings	1-24 hour delay, control lock, heated dry, hi temp wash, prodry, proscrub, sani rinse
Delay Start	yes
Child Lock	no
Load Sensor	yes
Number of Racks	2
Cycle Signal	no
Water Filter	yes
Water Softener	no
Food Disposer	no
Sanitize Settings	no
Annual Energy Consumption	270 kilowatt hours
Water Consumption Per Cycle	5.2 gallons
Voltage	120 volts
Current	120 amperes

Weight and Dimensions

Depth	24 3/4 inches
Height	34 1/2 inches
Width	23 7/8 inches
Net Weight	113 pounds
