KitchenAid KFP1322 - Remove Power Cord

- 8 -
7. Remove the 2 Phillips Screws in the cord cleat.(Fig. 4)
8. Loosen the 2 flat head screws that hold the white and black power wires (blue and brown power wires on
International).(Fig. 4)
Fig. 4) Remove Cord
9. Remove the 1 Phillips head screw for the speed sensor and remove it from the motor.(Fig. 5)
Fig. 5) Remove the speed sensor
Filter for International Models
