Microwave Oven Hood Combo Service Manual — LIT 4317216
Original 03/97
POWER
CORD
POWER
CORD COVER
BASE
PLATE
RED
WHITE
(2) RED
(2) WHITE
COOKTOP LIGHT
ASSEMBLY WIRING
WIRES
CABINET
CABINET
SCREW
VENT
GRILLE
SCREWS (2)
CABINET
SCREWS
VENT
GRILLE
BASE PLATE
SCREWS
(6)
Removing The Cabinet
